比力器

VSport官网提供的比力器产品蕴含开漏输出和推挽输出两类。

产品选择器

8 个了局

Part No	Status	Supply Voltage Range Vs (V) Min	Supply Voltage Range Vs (V) Max	Channel	Output Type	Input Hysteresis (mV)	Propogation Delay (ns) 100mV Overdrive, High to Low	Propogation Delay (ns) 100mV Overdrive, Low to High	Power Consumption, mA/Ch	Input Offset, max, mV	Input Offset Drift, Max, uV/degC	VCM (V) Min	VCM (V) Max	CMRR (dB) Vs-5.5V	Temperature operating Range (°C)	Package
GD30CP331	MP	1.8	5.5	1	Open drain	3	100	150	0.06	+/-5	+/-2	Vsm-0.1	Vsp+0.1	58	-40~85	SOT23-5L, SC70-5L
GD30CP393	MP	1.8	5.5	2	Open drain	3	100	150	0.06	+/-5	+/-2	Vsm-0.1	Vsp+0.1	58	-40~85	SOIC-8L, MSOP-8L TSSOP-8L, DFN2x2-8L
GD30CP8721	MP	1.7	5.5	1	Push pull	3	66	78	0.046	+/-4	+/-1	Vsm-0.1	Vsp+0.1	55	-40~85	SOT23-5L, SC70-5L
GD30CP8722	MP	1.7	5.5	2	Push pull	3	66	78	0.046	+/-4	+/-1	Vsm-0.1	Vsp+0.1	55	-40~85	SOIC-8L, MSOP-8 DFN2x2-8L
GD30CP2903	MP	3	36	2	Open collector	NA	300 (TTL input level setp	1300 (100mV Input Step With 5mV Overdrive)	0.65	+/-15	NA	Vsm	Vsp-2	NA	-40~125	SOIC-8L, MSOP-8L
GD30CP2901	MP	3	36	4	Open collector	NA	300 (TTL input level setp	1300 (100mV Input Step With 5mV Overdrive)	1.15	+/-15	NA	Vsm	Vsp-2	NA	-40~125	SOIC-14L, TSSOP-14L
GD30CP3201	MP	2.7	5.5	1	Push pull	10	30	30	0.045	+/-10	2	Vsm-0.1	vsp+0.1	55	-40~125	SOT23-5L
GD30CP3202	MP	2.7	5.5	2	Push pull	10	30	30	0.045	+/-10	2	Vsm-0.1	vsp+0.1	55	-40~125	SOIC-8L/MSOP-8L
