产品选择器
3 个了局
Loading
|
Part No
|
Supply Voltage (V) Min
|
Supply Voltage (V) Max
|
Norminal Current (A)
|
Current Limit (A)
|
Power MOSFET (mohm)
|
Control Interface
|
Current Sensor
|
High/Low MOSFET Switch Type
|
L Mode Protection Strategy
|
C Mode Protection Strategy
|
PWM Frequency (kHz) Max
|
VOUT Fast Discharger Path
|
Channel
|
Load Type
|
Protection Features
|
Fault Indicator
|
Temperature Operating Range (°C)
|
Package
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4.5 | 32 | 3.3 | 4.1 | 240 | PWM | Internal | Pin Set | Itrip | Current Limit | 200KHz | Support | 1 | Pin set for R/C/L loads | OCP/SCP/TSD/UVLO | Support | ?40°C to +125°C | EP-SOP8 | |
| 4.5 | 32 | 2 | 3 | 240 | PWM | Internal | High-Side | Itrip | Current Limit | 200KHz | Support | 1 | Pin set for R/C/L loads | OCP/SCP/TSD/UVLO | - | ?40°C to +125°C | SOT23-6 | |
| 4.5 | 32 | 2 | 3 | 240 | PWM | Internal | Low-Side | Itrip | - | 200KHz | - | 1 | R/L Loads | OCP/SCP/TSD/UVLO | - | ?40°C to +125°C | SOT23-6 |
